[box type=”bio”] Learning Point of the Article: [/box]
Low Vitamin D levels in elderly post-menopausal patients leads to osteopenia and needs to be considered as a crucial predisposing factor for long bones fracture.
Case Report | Volume 10 | Issue 8 | JOCR November 2020 | Page 19-22 | Sorabh Garg, Jagdeep Singh, Raj Bahadur, Swarnesh Bhaskaran. DOI: 10.13107/jocr.2020.v10.i08.1840
Authors: Sorabh Garg[1], Jagdeep Singh[1], Raj Bahadur[1], Swarnesh Bhaskaran[1]
[1]Department of Orthopaedics, Guru Gobind Singh Medical College and Hospital, Faridkot, Punjab, India.
Address of Correspondence:
Dr. Sorabh Garg,
Department of Orthopaedics, Guru Gobind Singh Medical College and Hospital, Faridkot, Punjab, India.
E-mail: sorgag@gmail.com
Abstract
Introduction: Simultaneous bilateral neck of femur fracture is rare. Majority of them are due to low energy incidents with underlying conditions such as malnutrition, chronic renal failure, cystic fibrosis, celiac disease, seizures, steroid abuse, or osteomalacia.
Case Report: A 68-year-old woman was referred with a 1-year history of bilateral hip pain and a 9-month history of inability to bear weight. She was diagnosed as a displaced bilateral femoral neck fracture secondary to osteomalacia. Due to the long duration of this condition and associated comorbidities, staged bilateral hip hemiarthroplasty was done. A good function was noted after surgery to 4-month follow-up.
Conclusion: Osteomalacia should be suspected in any patient with long-standing bone pain and muscle weakness regardless of age. Numerous options in the form of percutaneous screws, bipolar hemiarthroplasty, and total hip arthroplasty have been mentioned in the literature regarding the management of simultaneous bilateral femoral neck fractures. Staged bipolar hemiarthroplasty was done due to the associated comorbidities.
Keywords: Neck femur, osteomalacia, hemiarthroplasty.
Introduction
Simultaneous bilateral femoral neck fractures are extremely rare and have been associated with high-energy trauma [1], or due to underlying conditions such as celiac disease [2], malnutrition-induced osteomalacia [3, 4], cystic fibrosis [5], steroid abuse [6], and eclampsia-induced seizures [7]. Osteomalacia is a disorder which results in inadequate mineralization of newly formed organic matrix due to low levels of serum Vitamin D. It can lead to muscle weakness and bone pain and even rendering the patient bedridden [8]. Numerous treatment methods have been described in the literature for managing simultaneous bilateral neck femur fractures such as percutaneous screws, fixation with valgus osteotomy [9], and bipolar or total hip arthroplasty [7].
Case Report
A 68-year-old woman presented with a 1-year history of chronic pain in both hips. Pain was dull aching, progressive, and insidious in onset. For 3 months, she used a stick for weight-bearing until a day after a trivial fall, she developed acute, sharp shooting pain over the left hip region. Due to financial constraints, the patient remained bedridden for the next 9 months. She used to take some medication in the form of pain killers. About a month before, the patient visited a local doctor who took a “plain pelvic with both hips” radiograph which revealed displaced bilateral femoral neck fracture.
Patient’s medical history included ST-elevation myocardial infarction 2 years back, for which she was taking cardiac medications. There was no history of smoking or alcohol intake, Koch’s disease. On examination, both active and passive motions were restricted with contracture of adductor musculature on both sides. Fixed flexion deformity was noticed on the left side. Active straight leg raise (SLR) was not possible on either side. No limb-length discrepancy was observed due to the symmetrical nature of the deformity. Laboratory tests revealed serum calcium 7.0 mg/dl (8.5–10.5 mg/dL), serum phosphorus 2.3 mg/dl (2.5–4.5 mg/dl), alkaline phosphatase 180 IU/L (44-147 IU/L), and 25 hydroxy-Vitamin D 9.8 ng/ml (<20 ng/ml is considered as deficiency). Serum parathyroid hormone level was 90 pg/ml, pointing toward hyperparathyroidism (15–65 pg/ml). Her serum iron levels were normal. Due to the low socioeconomic status, bone densitometry was not obtained. However, an upper gastrointestinal endoscopy was done to rule out celiac disease which can lead to intestinal mal-absorption resulting in Vitamin D deficiency, leading to bilateral femoral neck fractures. The patient was diagnosed with bilateral fracture neck of femur secondary to osteomalacia (Fig. 1) and decision to operate was taken. Due to the cardiovascular risk, the anesthesia team preferred to do staged hemiarthroplasty rather than single-stage hemiarthroplasty which was our initial plan. The patient was operated under regional epidural anesthesia. Hemiarthroplasty with bilateral modular prosthesis was performed in a lateral position with one hip at a time (Fig. 2a, 2b). The cartilage of the acetabulum was intact, and the heads of the femurs were decided to be replaced with bipolar prosthesis. Post-operative radiographs were obtained on the 1st post-operative day. The patient was encouraged to do static quadriceps and active-assisted/active SLR exercises once the patient feels comfortable. The patient was made to sit on the bedside and full bearing walking with walker was started 24 h after the surgery. The patient was discharged from the hospital 7 days after surgery after confirming healthy wound status. The patient was given subcutaneous enoxaparin for deep vein thrombosis prophylaxis and injection of Vitamin D supplementation to correct the deficiency followed by oral Vitamin D sachets per weekly for 2 months. At 1-week follow-up, sutures were removed. Four weeks later, the patient was able to walk without support. After a follow of 1 year, she was walking comfortably without the support and her serum Vitamin D had returned to normal levels.
Discussion
Simultaneous, bilateral neck of femur fractures may be considered rare, and there have been few cases reported in the literature. Earlier, such injuries were seen in association with powerful muscular contractions induced by electroconvulsive therapies [10]. Since then, these have been associated with high-energy trauma [1], or due to underlying conditions such as celiac disease2, malnutrition-induced osteomalacia [3, 4] cystic fibrosis [5], steroid abuse [6], and eclampsia-induced seizures [7]. Carter et al. have reported a case 67-year-old female sustaining bilateral femoral neck fractures secondary to combined Vitamin D deficiency and steroid use [11]. Narcotic drug abuse can also lead to bilateral femoral neck fracture, as reported by Hootkani et al. [12] Selek et al. reported three patients sustaining simultaneous bilateral femoral neck fractures due to osteomalacia secondary to celiac disease [13]. Bilateral femur neck fractures can also occur in children, as reported by Upadhyay et al. [14]. Osteomalacia is a disorder of mineralization of newly synthesized organic matrix secondary to Vitamin D deficiency in adults. It is due to the combined result of inadequate dietary intake or intestinal mal-absorption and deficient sun exposure as in the present case. Numerous treatment methods have been described in the literature for managing simultaneous bilateral neck femur fractures such as percutaneous screws, fixation with valgus osteotomy9, and bipolar or total hip arthroplasty [7]. Sood et al. [15] described single-stage treatment of bilateral hip fractures in the form of bilateral hemiarthroplasty in supine position through anterolateral approach, but we could not opt for single-stage procedure due to the cardiovascular risk and did staged bipolar hemiarthroplasty and the recovery of the patient was uneventful.
Conclusion
Serum levels of Vitamin D should be measured in any patient presenting with long-standing bone pains and muscle weakness for the evaluation of osteomalacia. The underlying cause of osteomalacia must be diagnosed to improve the outcome. Nutritional osteomalacia is one of the cause, which can lead to bilateral neck femur fractures and, therefore, individuals presenting with such clinical scenarios to be considered for the Vitamin D, serum calcium, phosphorus, alkaline phosphatase, and parathyroid hormone workup.
Clinical Message
Bilateral neck femur fracture is a rare entity. The management of the elderly postmenopausal patient with long-standing and poorly managed bilateral hip pain, especially in the patient with malnutrition, needs utmost care. Early detection, clinical awareness, and appropriate laboratory workup undertaken to seek better treatment. Pertinent management, both medical and surgical, can provide better treatment outcomes with lesser chances of post-operative complications.
References
1. Schroder J, Marti RK. Simultaneous bilateral femoral neck fractures: Case report. Swiss Surg 2001;7:222-4.
2. Rubinstein A, Liron M, Bodner G. Bilateral femoral neck fractures as a result of coeliac disease. Postgrad Med J 1982;58:61-2.
3. Chadha M, Balain B, Maini L. Spontaneous bilateral displaced femoral neckfractures in nutritional osteomalacia-a case report. Acta Orthop Scand 2001;72:94-6.
4. Nagao S, Ito K, Nakamura I. Spontaneous bilateral femoral neck fractures associated with a low serum level of Vitamin D in a young adult. J Arthroplasty 2009;24:322e1-4.
5. Lim AY, Isopescu S, Thickett KM. Bilateral fractured neck of the femur in an adult patient with cystic fibrosis. Eur J Intern Med 2003;14:196-8.
6. Haddad FS, Mohanna PN. Goddard NJ. Bilateral femoral neck stress fractures following steroid treatment. Injury 1997;28:671-3.
7. Grimaldi M, Vouaillat H, Tonetti J, Merloz P. Simultaneous bilateral femoral neck fractures secondary to epileptic seizures: Treatment by bilateral total hip arthroplasty. Orthop Traumatol Surg Res 2009;95:555-7.
8. Lorenzo JA, Canalis E, Raisz LJ. Metabolic bone disease. In: Melmed S, Polonsky KS, Larsen PR, Kronenberg HM, editors. Williams Textbook of Endocrinology. 12th ed. Philadelphia, PA: Elsevier, Saunders; 2011. p. 1328.
9. Narender MK, Rajesh R, Gulia AD, Roop S. Valgus intertrochanteric osteotomy in neglected simultaneous, bilateral, displaced subcapital femoral neck fractures in an epileptic pregnant woman. Curr Orthop Pract 2009;20:461-3.
10. Powell HD. Simultaneous bilateral fractures of the neck of the femur. J Bone Joint Surg 1960;42B:236-52.
11. Carter T, Nutt J, Simons A. Bilateral femoral neck insufficiency fractures secondary to Vitamin D deficiency and concurrent corticosteroid use-a case report. Arch Osteoporos 2014;9:172.
12. Hootkani A, Moradi A, Vahedi E. Neglected simultaneous bilateral femoral neck fractures secondary to narcotic drug abuse treated by bilateral one-staged hemiarthroplasty: A case report. J Orthop Surg Res 2010;5:41.
13. Selek O, Memisoglu K, Selek A. Bilateral femoral neck fatigue fracture due to osteomalacia secondary to celiac disease: Report of three cases. Arch Iran Med 2015;18:542-4.
14. Upadhyay A, Maini L, Batra S. Simultaneous bilateral fractures of femoral neck in children-mechanism of injury. Injury 2004;35:1073-5.
15. Sood A, Rao C, Holloway I. Bilateral femoral neck fractures in an adult male following minimal trauma after a simple mechanical fall: A case report. Cases J 2009;2:92.
 |
 |
 |
 |
| Dr. Sorabh Garg | Dr. Jagdeep Singh | Dr. Raj Bahadur | Dr. Swarnesh Bhaskaran |
| How to Cite This Article: Garg S, Singh J, Bahadur R, Bhaskaran S. Nutritional Osteomalacia-Induced Bilateral Neck Femur Fracture in an Elderly Patient: A Case Report. Journal of Orthopaedic Case Reports 2020 November;10(8): 19-22. |
